Battery Charger LC-2256 Series

3-stage charging

LED indicator

Protected against reverse polarity

  • Battery Charger
  • Battery Charger
  • Battery Charger
  • Battery Charger

Battery Charger LC-2256 Series

Car Battery Charger Features

1. It is suitable for charging and maintaining 6V and 12V lead-acid batteries and 12V lithium iron phosphate batteries;

2. Suitable for all kinds of motorcycles, automobiles, toy cars, scooters, battery cars, charging, and maintenance

3. The charging current of this series of chargers can choose 2A(LC2256), 3A(LC-2257), 4A(LC-2258)

4. Different charging rates can be selected according to the battery capacity. Suitable for lead-acid batteries with a capacity of     3AH-50AH

5.  Support 0V ultra-low battery voltage to start charging, intelligent control pulse, and high-voltage mode to activate the vulcanized battery, which can effectively repair and maintain the deeply deprived battery.

6.  It adopts an MCU microprocessor to control the 5-stage charging mode, charging enough, but not charging

7. The shell adopts an IP65 waterproof design, which is better protected and safer to use.

 Battery Charger Specifications
SPECIFICATIONSLC-2256 LC-2257LC-2258
AC input voltage 90Vac~132Vac/185Vac~264Vac 90Vac~132Vac/185Vac~264Vac 90Vac~132Vac/185Vac~264Vac
AC input frequency 47Hz~63Hz 47Hz~63Hz 47Hz~63Hz
AC input power 40W 56W 75W
Battery voltage is   optional 6V,12V 6V,12V 6V,12V
Battery type is             optional SLA AGM GEL Lithium SLA AGM GEL Lithium SLA AGM GEL Lithium
Charging power30 W45 W60 W
Charging voltage     range 0~15.5Vdc 0~15.5Vdc 0~15.5Vdc
Charging current2A3A4A
Charging voltage 14.7V/7.35V 14.7V/7.35V 14.7V/7.35V
Light switching            current 0.4A 0.5A 0.5A
Float charging              voltage 13.65V/6.8V 13.65V/6.8V 13.65V/6.8V
Efficiency 85% 85% 85%
Overload Protection YES YES YES
Short Circuit              Protection YES YES YES
Reverse Polarity        Protection YES YES YES

Operating                   temperature
0℃~40℃ 0℃~40℃ 0℃~40℃
Dimension (mm) 167*72*40mm 167*72*40mm 167*72*40mm
