LC-2216 Series

Temperature-compensated

Unique Gel Cell battery

Multi-stage charging program

  • 1
  • 1
  • 1
  • 1
  • 1

LC-2216 Series

Features

1. Keep the battery charged and can be connected full time without overcharging;

2. Temperature-compensated to ensure optimum charge voltage according to ambient temperature;

3. Unique Gel Cell battery adjusted software allows for a slightly lower charge voltage and higher store voltage to protect sensitive true Gel Cell batteries;

4. Multi-stage charging program allows for optimal constant battery levels without overcharging;

5. Automatically switches to float/mainenance voltage mode after fully charging the battery.

Specifications
ParameterLC-2216LC4-24-3ALC-2217
Input Voltage100~240V AC100~240V AC100~240V AC
Output Frequency50~60Hz50~60Hz50~60Hz
Output Voltage12V24V36V
Output Current6A3A1.9A
Battery Type (AH)20-60434036.7-20
Light Switching Current1.2A0.6A0.38A
Overload ProtectionYesYesYes
Short Circuit ProtectionYesYesYes
Reverse Polarity ProtectionYesYesYes
Charging Status DisplayLEDLEDLED
CasePlasticPlasticPlastic
Dimension (MM)158*90*52158*90*52158*90*52
N.W610g610g610g
CertificationULULUL
