Multiple purposes utility vehicle
IHigh quality accessory parts
Comfortable driving experience
1. Driving system: Series shunt-wound motor brings you unbelievable climbing power;
2. Functional collocation: Rear basket and flip-flop seat;
3. CE for whole carts;
4. Including cigarette socket;
5. Accelerator: Adjustable inductive accelerator continuously variable speed system;
6. Leaf spring with Hydraulic shock absorbers;
7. Can modify the rear basket to be a rear seat or rear cargo;
8. 4 wheels hydraulic disk or Rear mechanical drum brake and Regeneration brake for optional;
| Model | DH-C2+2 | Gross weight: | 550kg |
| Passenger capacity: | 4 | Carrying capacity: | 360kg |
| Battery: | AGM Battery 8V * 6 PCS | Steering: | Rack&Pinion''Steering |
| Motor: | 48V 4KW | Brakes: | Rear Wheel Mechanical Drum Brake |
| Controller: | AC 48V 400A | Tire: | 10-inch steel rim wheel terrain tire |
| Charger: | On board charger | Wheel base | 1740mm |
| Max.Speed: | 30km/h | Overall dimension: | 2910*1300*1860mm |
| Max. traveling range: | 70 km | Ground clearance | 1100*675*160mm |
| Climbing capacity: | 30% | Seat | Rear Flip Flop Seat Plastic Molded |
| Brake range: | 6m | Standard parts: | Front/rear basket, front bumper, light system. |
| Minmum turning radius: | 4m | Optional parts: | Side mirror,Innermirror, Seatbelts, Weatherenclosure, Sunshadecurtain, Police light, PA system, CD player, rear-facing seat kit, Trojan Battery |
